  • Roadway/Corridor Surveys (Roadway design and Topo).
  • Topographic Survey/General Surveys (Boundary/Land Title Surveys).
  • Wi-Fi WiFi, 2.4 GHz Spread Spectrum, cabled (USB 2.0).
  • Plummet Type Built-in video plummet, Split optics tribrach with optical plummet.
  • Battery Life One internal battery: Approx.
  • Scan Speed Up to 26,600 Hz at ranges up to 600 m.
  • #Trimble business center scans software#

    Trimble touts the SX10 as having no learning curve, as it integrates directly with the Trimble software which their customers are already utilizing. It scans at a range of 600 meters, using a spot size of 14 millimeters in 100 meters. This Employed SX10 steps at 26,600 points each second, with a 360° by 300° area of view.

  • You need a high-accuracy (1”) total station but you can’t justify the expense of a standalone 3D scanner.
  • Most of your work requires a high-accuracy total station, but occasionally you also need a rapid and precise 3D scanning solution.
  • You don’t have a 3D scanner yet, but you’d like to have one in the future.
  • #Trimble business center scans how to#

    You already know how to use Trimble Access or another field workflow, and you’d like an easy introduction to 3D scanning work.You’d like to offer 3D scanning services, but you’re not familiar or quite confident with the workflow.You’d like to expand the services and deliverables you offer to customers and grow your business.

    trimble business center scans

    Used Trimble SX10 Scanning Total Station to capture both higher precision total station measurements and true high-speed 3D scans together in a single instrument. This configuration enables surveyors to gather camera images in addition to the exact 3D dimension in the area without adding any steps to their conventional surveying workflows. The innovative solution supplies surveyors and geospatial professionals together with the abilities and versatility to deal with jobs from conventional surveys to complex 3D modeling. Used Trimble SX10 combines high-speed 3D scanning, enhanced Trimble VISION imaging technology, and high-accuracy total station measurements into the familiar area and office workflows for surveyors. Complete integration with familiar workflows of Trimble Access and Trimble Business Center Software.ģD Scanner and a Total Station in One Device.Improved Trimble VISION™ technology allows for fast and easy capture of high-resolution site imagery.Utilizes Trimble Lightning scanning technology to scan up to 26,600 points per second captures a full-dome scan in as little as 12 minutes.Trimble’s high accuracy Lightning 3DM technology provides a scanning range up to 600 m and the smallest spot size in the industry-a mere 14 mm at 100 m.Combines surveying, imaging, and high-speed 3D scanning in one revolutionary solution.Since georeferencing is possible either directly or indirectly using this device, data processed both ways are also compared to conclude about the more reliable method. These different datasets are used to assess the Trimble SX10 issued point clouds through a set of comparisons. Next to the laser scanning survey, a photogrammetry campaign using an Unmanned Aerial Vehicle (UAV) has been carried out. The analyses mainly focus on the survey of a building facade. Trimble SX10 which was launched on the market in early October 2016 has been tested and some experiences carried out with it are reported in this paper. We’re confident we can provide the highest quality of surveying services to all of our projects, no matter the type, and we’re able to do that with current technology and software like the Trimble SX10 Scanner. SX10 combines surveying, imaging, and 3D scanning into one instrument, and helped collect data points of the retaining wall, which has multiple layers and varying textures along the wall. This allows us to complete a project of this nature with one piece of equipment and therefore saves our patrons money. The Trimble SX10 is also a Robotic Total Station, which allows us to collect data conventionally. The point cloud is, in essence, a three-dimensional rendering of the retaining wall that resembles a photo. Trimble SX10 instrument quickly creates a point cloud with millions of points of the retaining wall.
